PowerSyntax High Current Lithium Battery Connector 150A Part No MB150SIB

    Buy cheap PowerSyntax High Current Lithium Battery Connector 150A Part No MB150SIB from wholesalers

    Buy cheap PowerSyntax High Current Lithium Battery Connector 150A Part No MB150SIB from wholesalers
    • Buy cheap PowerSyntax High Current Lithium Battery Connector 150A Part No MB150SIB from wholesalers

    PowerSyntax High Current Lithium Battery Connector 150A Part No MB150SIB

    Ask Lasest Price
    Brand Name : PowerSyntax
    Model Number : MB150SIB
    Certification : IEC 529, EN 60529; IEC 309, EN 60309
    Payment Terms : T/T, Western Union
    Supply Ability : 1000pcs/month
    Delivery Time : 2-3 weeks
    • Product Details
    • Company Profile

    PowerSyntax High Current Lithium Battery Connector 150A Part No MB150SIB

    PowerSyntax High Current Lithium Battery Connector 150A For Positive Electrode With Inner Thread Screw Connection Part No. MB150SIB


    Technical Parameters:

    AttributeValue
    Brand / ManufacturerPowerSyntax
    Manufacturer Part NumberMB150SIB
    Mounting TypeCable Mount
    Pole FormatSingle Pole
    Current Rating (Ampere)150A
    Voltage RatingUp to 600VAC/VDC
    Ambient Temperature-20 ℃ to +125 ℃
    Flame retardant gradeV0
    Color option

    ☐ Orange for positive electrode MB150SIO

    ☑️ Black for negative electrode MB150SIB

    Frequency (Hertz)50-60 Hz
    Contact resistance0.3mΩ maximum contact resistance at DC 1A
    Insulation resistance5000MΩ minimum insulation resistance at 250VDC
    Connection TechnologyInner Thread Screw Terminal
    Material of Plastic HousingFlame retardant PA66
    Material of Metal ContactsBrass
    International StandardIEC 529, EN 60529; IEC 309, EN 60309

    Dimension Drawing:

    PowerSyntax High Current Lithium Battery Connector 150A Part No MB150SIB


    Features and Benefits:

    PowerSyntax MB series High Current Battery Connectors are single position cable connectors that support 150A, 250A and up to 350A for storage batteries. The connectors combine ruggedness, reliability, and ease of assembly in a single-circuit storage battery connector. The HCT components also feature a small, right-angle receptacle that maintains a low profile to the battery unit, offering significant space savings. The series offers a guide key and color-coding to prevent mismating between the ± electrode with IP2X finger protection.


    • Rated up to 350A

    • 180° reversal mate allows flexible cabling.

    • Downsized receptacle saves space inside a battery unit.

    • Right angle plug saves space for cable wiring.

    • Safety design with IP2X finger protection.

    • Supports the use of a hard lock nut, eliminating the re-tightening process of male contact connection.

    • Guide key and color-coding prevent mismating between ± electrode.


    Customized Solutions:

    If standard solutions do not meet all the requirements of an application, customer-specific solutions are made upon the request.


    Application of the Portable Distribution Boxes, Industrial Plugs & Sockets:

    • Public Infrastructure Industries: Urban Rail Transit, Nuclear Per Station, Wind Power Station, Port, Dock, Airport, Tunnel, Metro, Bridge, Road, Construction Site, and etc.

    • Production and Processing Enterprises: Metal Processing Plant, Paper Mill, Cement Plant, Power Plant, Aluminum Manufacturer, Steel and Iron Works, Automobile Works, Sewage Treatment Plant, and etc.

    • Communication Industries: 4G Communication Equipment, 5G Communication Equipment, 5G Communication Station, GPS Equipment, WIFI Equipment, and etc.

    • Electronic Industries and Food Industries: Cellphone Automatic Production Line, Car Automatic Production Line, Food Automatic Production Line and etc.

    • Music and Sports Industries: Concert, Stadium, Presentation, Meeting Center, Hotel, Touring and Film equipment, and etc.

    • Civil Industries: Hospital, School, Bank, Square, Shopping Mall, Supermarket, and etc.

    • Electric Automobile Industries: Electric Cars Charger, Charger Distribution Box, Intelligent Charging System, and etc.
