    PowerSyntax IP67 Waterproof Hinged Inspection Window With Double Padlock For Customized Front Panels Part No. IF0406

    Ask Lasest Price
    Brand Name : Syntax
    Model Number : IF0406
    Certification : EN 60309, IEC 60529
    Payment Terms : T/T, Western Union
    Supply Ability : 100,000 pcs/month
    Delivery Time : 2-3 weeks
    • Product Details
    • Company Profile

    PowerSyntax IP67 Waterproof Hinged Inspection Window With Double Padlock For Customized Front Panels Part No. IF0406

    PowerSyntax IP67 Waterproof Hinged Inspection Window With Double Padlock For Customized Front Panels Part No. IF0406


    Dimension Drawing:


    Customize Modules Optional:


    Features:

    • Model No.: IF0406.

    • Specially designed for customized front panels.

    • Design based on EN 60309, IEC 60529.

    • Water resistant design, IP rating up to IP67.

    • Frame color: electric grey.

    • Windows are spring-loaded and secured with thumb screws.

    • With protective cover and knurled screws.

    • Material: PC (Polycarbonate Resin, a kind of plastic).

    • Temperature rating -25°C to +80°C.

    • External Dimensions: 149*114*26mm.


    Description:

    PowerSyntax IP67 Waterproof Hinged Inspection Window is specially designed window for protection of worldwide wall switches and sockets, fuse holders, computer interfaces like USB, type C, HDMI and etc.


    These front panel windows possess a high impact moulded transparent cover. The cover is spring loaded and is fitted with 2 knurled locking screws to ensure closure to IP67. And the cover has two padlocks design.


    They are protected to IP67 and are available in 2 dimensions, which is 99*114*26mm and 149*114*26mm. They contains most of the common countries’ sockets and computer interfaces.


    Remarks for the PC material: the PC material is almost the most expensive plastic material we can use for making plastic distribution boxes. It’s light, hard, strong and smooth.


    Customized Solutions:

    If standard solutions do not meet all the requirements of an application, customer-specific solutions are made upon the request.


    Applications:

    • Electrical
    • Button switching elements
    • Telecommunication
    • Network Junction boxes
    • Mechanical and automation
